| Technical Specification | |
|---|---|
| Camera | |
| Image Sensor | 1/2.7″ CMOS |
| Max. Resolution | 3840 (H) × 2160 (V) |
| ROM | 128 MB |
| RAM | 256 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.009 lux@F2.0 (Color, 30 IRE); 0.0009 lux@F2.0 (B/W, 30 IRE); 0 lux (IR on) |
| S/N Ratio | >56 dB |
| Illumination Distance | 30 m (98.43 ft) (IR) |
| Illuminator On/Off Control | Auto; Manual |
| Illuminator Number | 1 (IR LED) |
| Pan/Tilt/Rotation Range | Pan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360° |
| Lens | |
| Lens Type | Fixed-focal |
| Lens Mount | M12 |
| Focal Length | 2.8 mm; 3.6 mm |
| Max. Aperture | F2.0 |
| Field of View | 2.8 mm: H:106°; V:56°; D:125° / 3.6 mm: H:88°; V:46°; D:104° |
| Iris Control | Fixed |
| Close Focus Distance | 2.8 mm: 1.3 m / 3.6 mm: 1.9 m |
| DORI Distance | |
| 2.8 mm | Detect: 88.0 m; Observe: 35.2 m; Recognize: 17.6 m; Identify: 8.8 m |
| 3.6 mm | Detect: 106.7 m; Observe: 42.7 m; Recognize: 21.3 m; Identify: 10.7 m |
| Intelligence | |
| IVS (Perimeter Protection) | Intrusion, tripwire (support classification and accurate detection of vehicle and human) |
| Smart Search | Works with Smart NVR for intelligent search, event extraction and merging |
| Video | |
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (sub stream) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| Video Frame Rate | Main: 3840×2160@(1–20fps)/2688×1520@(1–25/30fps); Sub: 704×576@(1–25fps)/704×480@(1–30fps) |
| Stream Capability | 2 streams |
| Resolution | 3840×2160; 3072×2048; 2688×1520; 2304×1296; 1080p; 720p; D1; VGA; CIF |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 32–8192 kbps; H.265: 12–8192 kbps |
| Day/Night | Auto(ICR)/Color/B/W |
| BLC / HLC / WDR | Yes / Yes / 120 dB |
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| Noise Reduction | 3D NR |
| Motion Detection | ON/OFF (4 areas) |
| Region of Interest | Yes (4 areas) |
| Smart Illumination | Yes |
| Image Rotation / Mirror | 0°/90°/180°/270° / Yes |
| Privacy Masking | 4 areas |
| Audio | |
| Built-in MIC | Yes |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Alarm | |
| Alarm Event | No SD card; SD card full/error; network disconnection; IP conflict; motion detection; video tampering; intrusion; audio detection; voltage detection; SMD; security exception |
| Network | |
| Network Port | RJ-45 (10/100 Base-T) |
| Protocols | IPv4; IPv6; HTTP; TCP; UDP; RTP; RTSP; SMTP; FTP; DHCP; DNS; DDNS; NTP; QoS; UPnP; P2P; IGMP; PPPoE |
| Interoperability | ONVIF (S/G/T); CGI; Milestone; P2P |
| Users | 20 (Total bandwidth: 48 M) |
| Storage | FTP; SFTP; Micro SD (max. 256 GB); NAS |
| Browser | IE; Chrome; Firefox |
| Software | Smart PSS; DSS; DMSS |
| Mobile Client | iOS; Android |
| Cyber Security | Encryption; HTTPS; account lockout; trusted boot; X.509 certificate; syslog |
| Certification | |
| Certifications | CE-LVD: EN62368-1; CE-EMC 2014/30/EU; FCC Part 15; UL62368-1; CAN/CSA C22.2 No. 62368-1-14 |
| Power | |
| Power Supply | 12 VDC/PoE (802.3af) |
| Power Consumption | Basic: 2.7 W (12 VDC); 3.4 W (PoE); Max: 4.5 W (12 VDC); 5.4 W (PoE) |
| Environment | |
| Operating Temperature | –40 °C to +60 °C |
| Operating Humidity | ≤95% |
| Storage Temperature | –40 °C to +60 °C |
| Storage Humidity | ≤95% |
| Protection | IP67 |
| Structure | |
| Casing Material | Metal |
| Product Dimensions | 166.2 × 70 × 70 mm (6.54″ × 2.76″ × 2.76″) |
| Net Weight | 0.48 kg |
| Gross Weight | 0.59 kg |
| Ordering Information | |
| Model | DH-IPC-HFW2841S-S |
| Description | 8MP IR Fixed-focal Bullet WizSense Network Camera |
| Accessories (Optional) | |
| PFA134 Junction Box; PFA130-E Waterproof Junction Box; PFA152-E Pole Mount Bracket; PFM321D 12VDC 1A Adapter; PFM900-E Integrated Mount Tester; TF-P100 MicroSD Card | |
