| Image Sensor | 1/2.7” 5Megapixel progressive CMOS |
| Max. Resolution | 2592 (H) × 1944 (V) |
| ROM | 128 MB |
| RAM | 512 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.003 Lux @ F1.0 |
| S/N Ratio | > 56 dB |
| Illumination Distance | 40 m (131.2 ft) |
| Illuminator On/Off Control | Auto/Manual |
| Illuminator Number | 2 (Warm light) |
| Pan/Tilt/Rotation Range | Pan: 0°–360° / Tilt: 0°–90° / Rotation: 0°–360° |
| Lens Type | Fixed-focal |
| Mount Type | M12 |
| Focal Length | 2.8 mm; 3.6 mm; 6 mm |
| Max. Aperture | F1.0 |
| Field of View | 2.8 mm: H 98° × V 71° × D 129° 3.6 mm: H 77° × V 56° × D 101° 6 mm: H 53° × V 40° × D 66° |
| Iris Type | Fixed |
| Close Focus Distance | 2.8 mm: 1.2 m (3.9 ft) 3.6 mm: 2.1 m (6.9 ft) 6 mm: 4.5 m (14.8 ft) |
| Lens | Detect | Observe | Recognize | Identify |
|---|---|---|---|---|
| 2.8 mm | 67.4 m (221.1 ft) | 27 m (88.6 ft) | 13.5 m (44.3 ft) | 6.7 m (22.0 ft) |
| 3.6 mm | 80.0 m (262.5 ft) | 32.0 m (105.0 ft) | 16.0 m (52.5 ft) | 8.0 m (26.2 ft) |
| 6 mm | 120.0 m (393.7 ft) | 48.0 m (157.5 ft) | 24.0 m (78.7 ft) | 12.0 m (39.4 ft) |
| IVS (Perimeter Protection) | Tripwire; intrusion (vehicle/human classification and detection) |
| Intelligent Search | Supports Smart NVR for refined search and event extraction |
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG |
| Smart Codec | Smart H.265+/Smart H.264+ |
| Frame Rate | Main: 2592×1944@1–20fps / 2688×1520@1–25/30fps Sub: 704×576@1–25fps / 704×480@1–20fps Third: 1920×1080@1–25/30fps |
| Stream Capability | 3 streams |
| Resolution | 5M, 4M, 3M, 1080p, 720p, D1, VGA, CIF |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 32 kbps–8192 kbps / H.265: 12 kbps–8192 kbps |
| WDR | 120 dB |
| Noise Reduction | 3D NR |
| Smart Illumination | Yes |
| Privacy Masking | 4 areas |
| Built-in MIC | Yes |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; G.723 |
| Interface | RJ-45 (10/100 Base-T) |
| Protocols | IPv4/IPv6, HTTP, TCP, UDP, RTP, RTSP, FTP, SFTP, DHCP, DNS, DDNS, NTP, SNMP, etc. |
| Cyber Security | Encryption, WSSE, IP/MAC filtering, HTTPS, 802.1x, Trusted boot |
| Interoperability | ONVIF (Profile S/G/T); CGI; Milestone; Genetec; P2P |
| Users | 20 users (Total bandwidth: 80 Mbps) |
| Storage | FTP, SFTP, Micro SD (max. 256G), NAS |
| Power Supply | 12V DC / PoE (802.3af) |
| Power Consumption | Max 7.5W (12V DC) / 8.8W (PoE) |
| Operating Conditions | –40°C to +60°C / <95% RH |
| Storage Conditions | –40°C to +60°C |
| Protection Grade | IP67 |
| Casing | Metal + Plastic |
| Dimensions | 288.4 × 94.4 × 84.7 mm (11.4″ × 3.7″ × 3.3″) |
| Net Weight | 1.0 kg (2.2 lb) |
| Gross Weight | 1.23 kg (2.7 lb) |
| Type | Part Number | Description |
|---|---|---|
| 5MP Camera | DH-IPC-HFW3549T1P-AS-PV | 5MP Full-color Active Deterrence Fixed-focal Bullet WizSense Network Camera, PAL |
| DH-IPC-HFW3549T1N-AS-PV | 5MP Full-color Active Deterrence Fixed-focal Bullet WizSense Network Camera, NTSC | |
| IPC-HFW3549T1P-AS-PV | 5MP Full-color Active Deterrence Fixed-focal Bullet WizSense Network Camera, PAL | |
| IPC-HFW3549T1N-AS-PV | 5MP Full-color Active Deterrence Fixed-focal Bullet WizSense Network Camera, NTSC |
| PFA130-E | Junction Box |
| PFA152-E | Pole Mount |
| PFM321D | 12V DC 1A Power Adapter |
| LR1002-1ET/1EC | Long Reach Ethernet over Coax Extender |
| PFM900-E | Integrated Mount Tester |
| PFM114 | TLC SD Card |
