| Image Sensor | 1/1.8″ CMOS |
| Max. Resolution | 3840 (H) × 2160 (V) |
| ROM | 4 GB |
| RAM | 2 GB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.0008 lux@F1.8 (Color, 30 IRE) 0.0004 lux@F1.8 (B/W, 30 IRE) 0 lux (Illuminator on) |
| S/N Ratio | >56 dB |
| Illumination Distance | Up to 60 m (196.85 ft) (IR) |
| Illuminator On/Off Control | Auto; Zoomprio; Manual |
| Illuminator Number | 4 (IR LED) |
| Angle Adjustment | Pan: 0°–360° / Tilt: 0°–90° / Rotation: 0°–360° |
| Lens Type | Motorized vari-focal |
| Lens Mount | φ14 |
| Focal Length | 2.7 mm–12 mm |
| Max. Aperture | F1.8 |
| Field of View | H: 113°–47°; V: 60°–26°; D: 133°–53° |
| Iris Control | Auto |
| Close Focus Distance | 1.5 m (4.92 ft) |
| Lens | Detect | Observe | Recognize | Identify |
|---|---|---|---|---|
| W | 83.4 m (273.62 ft) | 33.4 m (109.58 ft) | 16.7 m (54.79 ft) | 8.3 m (27.23 ft) |
| T | 189.6 m (622.05 ft) | 75.8 m (248.69 ft) | 37.9 m (124.34 ft) | 19.0 m (62.34 ft) |
| EPTZ | Yes |
| IVS (Perimeter Protection) | Intrusion, tripwire, fast moving, loitering detection, people gathering, parking detection; vehicle/animal/human classification supported |
| Smart Object Detection | Smart abandoned/missing object |
| SMD | SMD 3.0 |
| AcuPick | Deep learning algorithms to accurately match targets and search live/recorded videos |
| AI SSA | Yes |
| Face Detection | Detection, tracking, snapshot, face attributes extraction (6 attributes, 8 expressions), optimization |
| People Counting | Tripwire and area counting, queue management, daily/weekly/monthly reports |
| Heat Map | Yes |
| Video Metadata | Vehicle, non-vehicle, face, human body detection with attributes |
| Smart Search | Refined intelligent search via Smart NVR |
| Smart Sound Detection | Yes |
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (sub stream only) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| AI Coding | AI H.265; AI H.264 |
| Video Frame Rate | Main: 3840×2160@1–25/30fps; Sub: D1@1–25/30fps; Third: 1080p@1–25/30fps; Fourth: 720p@1–10fps |
| Stream Capability | 4 streams |
| Resolution | 8M, 6M, 5M, 4M, 3.6M, 3M, 1080p, 720p, D1, VGA, CIF |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 32–16384 kbps; H.265: 12–13568 kbps |
| Day/Night | Auto(ICR)/Color/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 120 dB |
| Scene Self-adaptation (SSA) | Yes |
| White Balance | Auto, natural, street lamp, outdoor, manual, regional custom |
| Gain Control | Auto |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Image Stabilization | Electronic Image Stabilization (EIS) |
| Smart Illumination | Yes |
| Defog | Yes |
| Image Rotation | 0°/90°/180°/270° (supports 90°/270° with 4M resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 8 areas |
| LDC | Yes |
