| Camera Specifications | |
|---|---|
| Camera | |
| Image Sensor | 1/3.2″ CMOS |
| Max. Resolution | 2304 × 1296 |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Illumination Distance | Up to 10 m (32.81 ft) (IR) |
| Illuminator On/Off Control | Auto |
| Illuminator Number | 1 (IR LED) |
| Angle Adjustment | Pan: 0° to 355°; Tilt: –5° to 80° |
| Lens | |
| Max. Aperture | F2.0 |
| Field of View | H: 73°, V: 41°, D: 88° |
| Intelligence | |
| Human Detection | Yes |
| Video | |
| Video Compression | H.265 |
| Video Frame Rate | Main stream: 2304 × 1296 @ 1–25/30 fps Sub stream: 640 × 360 @ 1–25/30 fps |
| Resolution | 3M (2304 × 1296); nHD (640 × 360) |
| Video Bit Rate | H.265: 80 kbps–4096 kbps |
| Day/Night | Auto(ICR)/Color/B&W |
| WDR | DWDR |
| Motion Detection | Yes |
| Image Rotation | 0°/180° |
| Audio | |
| Built-in MIC | Yes, built-in Mic |
| Built-in Speaker | Yes, built-in speaker |
| Audio Compression | G.711a |
| Network | |
| Network Port | RJ-45 (10/100 Base-T) |
| Wi-Fi | IEEE 802.11b/g/n/ax 2.412–2.472 GHz, 2.4G |
| Storage | Micro SD card (up to 256 GB) |
| Management Software | DMSS |
| Mobile Client | iOS; Android |
| Certification | |
| Certifications | CE |
| Power | |
| Power Supply | 5 VDC |
| Power Consumption | Basic: 1.6 W; Max: 3.6 W (live + IR + PT rotation) |
| Environment | |
| Operating Temperature | –10 °C to +45 °C (+14 °F to +113 °F) |
| Operating Humidity | ≤95% RH, non-condensing |
| Structure | |
| Casing Material | Plastic |
| Product Dimensions | φ77.8 mm × 108.1 mm (φ3.06″ × 4.26″) |
| Net Weight | 195 g (0.30 lb) |
