| Technical Specification | |
|---|---|
| Camera | |
| Image Sensor | 1/2.9″ CMOS |
| Max. Resolution | 2688 (H) × 1520 (V) |
| ROM | 128 MB |
| RAM | 512 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.005 lux@F1.4 (Color, 30 IRE); 0.0005 lux@F1.4 (B/W, 30 IRE); 0 lux (Illuminator on) |
| S/N Ratio | >56 dB |
| Illumination Distance | Up to 50 m (164.04 ft) |
| Illuminator On/Off Control | Auto/Manual |
| Illuminator Number | 1 (IR LED) |
| Pan/Tilt/Rotation Range | Pan: 0°–360°; Tilt: 0°–90°; Rotation: 0°–360° |
| Lens | |
| Lens Type | Fixed-focal |
| Lens Mount | M12 |
| Focal Length | 2.8 mm; 3.6 mm; 6 mm |
| Max. Aperture | F1.4 |
| Field of View | 2.8 mm: H107°/V56°/D127°; 3.6 mm: H88°/V44°/D105°; 6 mm: H54°/V29°/D63° |
| Iris Control | Fixed |
| Close Focus Distance | 2.8mm:0.7m; 3.6mm:1.3m; 6mm:2.6m |
| DORI Distance | |
| 2.8mm | Detect:63.6m; Observe:25.4m; Recognize:12.7m; Identify:6.4m |
| 3.6mm | Detect:85.4m; Observe:34.2m; Recognize:17.1m; Identify:8.5m |
| 6mm | Detect:124m; Observe:49.6m; Recognize:24.8m; Identify:12.4m |
| Intelligence | |
| IVS (Perimeter Protection) | Tripwire, intrusion (human/vehicle classification) |
| AI SSA | Yes |
| Quick Pick | Works with AI NVR for human/vehicle target extraction |
| Smart Search | Supports intelligent search and event extraction |
| Video | |
| Video Compression | H.265; H.264; MJPEG (sub stream only) |
| Smart Codec | Smart H.265+ / Smart H.264+ / AI H.265 / AI H.264 |
| Video Frame Rate | Main: 2688×1520@1–25/30fps; Sub1:704×576@1–25fps; Sub2:1920×1080@1–30fps |
| Resolution | 4M, 3M, 1080p, 720p, D1, VGA, CIF |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264/H.265: 3–8192 Kbps |
| Day/Night | Auto (ICR)/Color/B/W |
| BLC / HLC / WDR | Yes / Yes / 120 dB |
| Scene Self-adaptation (SSA) | Yes |
| Noise Reduction | 3D NR |
| Defog / AFSA | Yes / Yes |
| Privacy Masking | 4 areas |
| Audio | |
| Built-in MIC | Yes |
| Audio Compression | G.711a; G.711Mu; PCM; G.726; G.723 |
| Alarm | |
| Alarm Event | No SD card; full/error; motion; tamper; intrusion; tripwire; scene change; audio detection; voltage; SMD; safety exception |
| Network | |
| Network Port | RJ-45 (10/100 Base-T) |
| Protocols | IPv4/IPv6, HTTP, TCP, UDP, RTP, RTSP, SMTP, FTP, NTP, SNMP, P2P, etc. |
| Cyber Security | Video encryption, HTTPS, 802.1x, Trusted boot/execution/upgrade |
| Interoperability | ONVIF (S/G/T), CGI |
| Users | 20 (Total bandwidth: 64 M) |
| Storage | FTP/SFTP, Micro SD (max 256G), NAS |
| Browser | IE11, Chrome, Firefox |
| Software | SmartPSS Lite, DSS, DMSS |
| Power | |
| Power Supply | 12V DC / PoE (802.3af) |
| Power Consumption | Max 7.2W (PoE) |
| Environment | |
| Operating Temperature | –40 °C to +60 °C / <95%RH |
| Storage Temperature | –40 °C to +60 °C |
| Protection | IP67 |
| Structure | |
| Casing | Metal |
| Dimensions | 192.7 × 70.5 × 66.4 mm (7.59″ × 2.77″ × 2.61″) |
| Net Weight | 590 g |
| Gross Weight | 780 g |
| Ordering Information | |
| 4MP Camera | DH-IPC-HFW3441E-AS-S2 / DH-IPC-HFW3441E-S-S2 |
| Accessories | PFA130-E (Junction Box), PFA152-E (Pole Mount), PFM321D (Power Adapter), PFM900-E (Mount Tester), TF-P100 (SD Card) |
