| Camera | |
|---|---|
| Image Sensor | 1/2.9″, 2.0 megapixel, progressive scan, CMOS |
| Minimum Illumination | Colour: 0.005 Lux @ (F1.6, AGC ON) |
| Shutter | Auto/Manual, 1 ~ 1/100000 s |
| Adjustment Angle | Pan: 0° ~ 360°, Tilt: 0° ~ 90°, Rotate: 0° ~ 360° |
| WDR | DWDR |
| S/N | >52 dB |
| Lens | |
| Lens Type | 2.8 mm @ F1.6, 4.0 mm @ F1.6 |
| Iris | Fixed |
| Field of View | 2.8 mm: H 101.1°, V 55.0°, D 111.0° 4.0 mm: H 83.7°, V 44.6°, D 89.1° |
| DORI | |
| DORI Distance (2.8 mm) | Detect: 45.0 m (147.6 ft), Observe: 18.0 m (59.1 ft), Recognize: 9.0 m (29.5 ft), Identify: 4.5 m (14.8 ft) |
| DORI Distance (4.0 mm) | Detect: 64.3 m (210.9 ft), Observe: 25.7 m (84.4 ft), Recognize: 12.9 m (42.2 ft), Identify: 6.4 m (21.1 ft) |
| Illuminator | |
| Warm Light Range | Up to 30 m (98 ft) |
| Light On/Off Control | Auto/Manual |
| Video | |
| Video Compression | Ultra H.265, H.265, H.264 |
| Frame Rate | Main Stream: 2 MP (1920×1080), Max 30 fps; 720P (1280×720), Max 30 fps Sub Stream: D1 (720×576), Max 30 fps; 640×360, Max 30 fps; 2CIF (704×288), Max 30 fps; CIF (352×288), Max 30 fps |
| H.264 Code Profile | Baseline profile, Main profile, High profile |
| Video Bit Rate | 128 Kbps ~ 6144 Kbps |
| U-code | Support (Main stream) |
| OSD | Up to 4 OSDs |
| Privacy Mask | Up to 4 areas |
| ROI | Up to 8 areas |
| Video Stream | Dual streams |
| Image | |
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital Noise Reduction | 2D/3D DNR |
| Smart Illumination | Support |
| Flip | Normal/Flip Vertical/Flip Horizontal/180° |
| Dewarping | N/A |
| HLC | Support |
| BLC | Support |
| Defog | Digital Defog |
| Events | |
| Basic Detection | Motion detection, Audio Detection |
| General Function | Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP Authentication |
| Audio | |
| Audio Compression | G.711U, G.711A |
| Audio Bitrate | 64 Kbps |
| Two-way Audio | N/A |
| Suppression | Support |
| Sampling Rate | 8 KHz |
| Storage | |
| Edge Storage | Micro SD, up to 128 GB |
| Network | |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, UPnP, HTTP, HTTPS, QoS, SSL/TLS |
| Compatible Integration | ONVIF (Profile S, Profile T, Profile G), API, SDK |
| User/Host | Up to 32 users. 2 user levels: administrator and common user |
| Security | Password protection, strong password, HTTPS encryption, Export operation logs, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF |
| Client | EZStation, EZLive, EZView |
| Web Browser | Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+ Plug-in free live view: Chrome 57.0+, Firefox 58.0+, Edge 16+ |
| Interface | |
| Audio I/O | N/A |
| Alarm I/O | N/A |
| Serial Port | N/A |
| Built-in Mic | Support |
| Built-in Speaker | N/A |
| WIFI | N/A |
| Network | 1 × RJ45 10M/100M Base-TX Ethernet |
| Video Output | N/A |
| Certification | |
| EMC | CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 50130), FCC (FCC 47 CFR part15 B) |
| Safety | CE LVD (EN 62368-1), CB (IEC 62368-1), UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1) |
| Environment | CE-RoHS (2011/65/EU; (EU)2015/863), WEEE (2012/19/EU) |
| Protection | IP67 (IEC 60529) |
| General | |
| Power | DC 12V (±25%), PoE (IEEE 802.3af) |
| Power Consumption | Max 7.8 W |
| Power Interface | Ø 5.5 mm coaxial power plug |
| Dimensions | 162 × 67 × 67 mm (6.4” × 2.6” × 2.6”) |
| Weight | 0.24 kg (0.53 lb) |
| Material | Metal + Plastic |
| Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Storage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Surge Protection | 4 KV |
| Reset Button | N/A |
| Accessories | |
| Pole Mount | TR-JB05-B-IN, TR-JB05-B-IN + TR-UP06-C-IN |
| Junction Box | TR-UP06-C-IN |
