| Decoding Specifications | |
|---|---|
| Decoding Format | Ultra 265, H.265, H.264 |
| Audio Compression | G.711A, G.711U |
| Decoding Capability | |
| NVR301-04S3 | 1 × 4K@30, 4 × 5MP@25, 4 × 4MP@25, 4 × 3MP@25 |
| NVR301-08S3 | 1 × 4K@30, 4 × 5MP@25, 4 × 4MP@25, 4 × 3MP@25, 6 × 1080P@30, 8 × 720P@30 |
| NVR301-16S3 | 1 × 4K@30, 4 × 5MP@25, 4 × 4MP@25, 4 × 3MP@25, 6 × 1080P@30, 8 × 720P@30, 16 × D1@25 |
| Network Description | |
|---|---|
| Incoming Bandwidth | 64 Mbps |
| Outgoing Bandwidth | 48 Mbps |
| Remote Users | 128 |
| Supported Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SMTP, RTSP |
| Supported Browsers | Windows: IE (IE10/11), Firefox (v52+), Chrome (v45+), Edge (v79+) |
| Technical Specification | |
|---|---|
| System | |
| Main Processor | Industrial-grade processor |
| Operating System | Embedded Linux |
| Operating Interface | Web, Local GUI |
| AI | |
| AI by Recorder | Face detection; face recognition; perimeter protection; SMD |
| Video/Audio Input | |
| IP Video Input | NVR301-04S3: 4-ch NVR301-08S3: 8-ch NVR301-16S3: 16-ch |
| Video/Audio Output | |
| HDMI Output | HDMI: 4K (3840×2160)/30Hz, 1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
| VGA Output | VGA: 1920×1080/60Hz, 1920×1080/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
| 3.5mm Audio Output | 1-ch |
| Liveview Display | |
| Display Modes | NVR301-04S3: 1/4 NVR301-08S3: 1/4/6/8/9 NVR301-16S3: 1/4/6/8/9/16 |
| Corridor Mode Screen | NVR301-04S3: 3/4 NVR301-08S3: 3/4/5/7/9 NVR301-16S3: 3/4/5/7/9/10/12/16 |
| Snapshot | |
| FTP/Schedule/Event Snapshot | 1-ch snapshot, up to D1 resolution |
| Recording | |
| Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/2CIF/CIF |
| Synchronous Playback in Local | NVR301-04S3: 4-ch NVR301-08S3: 8-ch NVR301-16S3: 16-ch |
| Smart | |
| VCA Detection by IPC | Face Detection; SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area); Ultra Motion Detection (UMD) |
| VCA Search | Behavior Search |
| Smart by IPC | Total 4-ch (Face Detection, SIP, UMD) |
| Capacity of Snapshot Records | 2 million records for face snapshot |
| Alarm | |
| General Alarm | Auto Tracking; Motion Detection; Tampering; Human Body Detection; Video Loss; Alarm Input; Audio Detection |
| Alert Alarm | IP Conflict; Network Disconnected; Disk Offline; Disk Abnormal; Illegal Access; Hard Disk Space Low; Hard Disk Full; Recording/Snapshot Abnormal |
| GUI Language | |
| Supported Languages | 21 languages: Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian |
