| Technical Specification | |
|---|---|
| Decoding | |
| Decoding Format | Ultra H.265, H.265, H.264 |
| NVR302-09B-IQ | Smart Off: 2×12MP@30, 2×4K@30, 4×4MP@30, 9×1080P@30 Smart On: 2×4K@30, 4×4MP@30, 8×1080P@30, 9×720P@30 |
| NVR302-16B-IQ | Smart Off: 2×12MP@30, 2×4K@30, 4×4MP@30, 10×1080P@30, 16×720P@30 Smart On: 2×4K@30, 4×4MP@30, 8×1080P@30, 16×720P@30 |
| NVR302-32B-IQ | Smart Off: 2×12MP@30, 2×4K@30, 4×4MP@30, 10×1080P@30, 20×720P@30, 32×D1 Smart On: 2×4K@30, 4×4MP@30, 8×1080P@30, 16×720P@30, 32×D1 |
| Audio Compression | G.711A, G.711U |
| Network | |
| Incoming Bandwidth | 160 Mbps |
| Outgoing Bandwidth | 128 Mbps |
| Remote Users | 128 |
| Protocols | TCP/IP, P2P, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, RTSP, IPv4/IPv6 |
| Browser (Plugin) | Windows: IE10/11, Firefox ≥52, Chrome ≥45, Edge ≥79 |
| Video/Audio Input | |
| IP Video Input | NVR302-09B-IQ: 9-ch, NVR302-16B-IQ: 16-ch, NVR302-32B-IQ: 32-ch |
| RCA Audio Input | 1-ch |
| Video/Audio Output | |
| HDMI Output | 4K/30Hz, 1080p/60Hz, 1080p/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
| VGA Output | 1080p/60Hz, 1080p/50Hz, 1600×1200/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
| RCA Audio Output | 1-ch |
| Display & Playback | |
| Liveview | NVR302-09B-IQ: 1/4/6/8/9 NVR302-16B-IQ: 1/4/6/8/9/16 NVR302-32B-IQ: 1/4/6/8/9/16/25/32 |
| Playback | NVR302-09B-IQ: 1/4/9 NVR302-16B-IQ & NVR302-32B-IQ: 1/4/9/16 |
| Two-way Audio & Snapshot | |
| Two-way Audio | 1-ch, RCA (using input/output) |
| Snapshot | FTP/Schedule/Event, 4-ch snapshot up to D1 resolution |
| Recording | |
| Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/2CIF/CIF |
| Synchronous Playback | NVR302-09B-IQ: 9-ch, NVR302-16B-IQ & NVR302-32B-IQ: 16-ch |
| Smart Features | |
| VCA Detection by IPC | Face Detection, Vehicle Detection, SIP, UMD, People Counting, Traffic Monitoring |
| Smart by NVR | Face Detection, SIP, UMD, People Counting, Heat Map |
| Vehicle Picture Library | Up to 5 libraries, 25,000 vehicle pictures total |
| Alarm | |
| General Alarm | Defocus Detection, Scene Change, Object Left Behind/Removed, Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection |
| Alert Alarm | IP Conflict, Network Disconnected, Disk Offline/Abnormal, Illegal Access, HDD Low/Full, Recording/Snapshot Abnormal |
| Hardware | |
| Hard Disk | 2×SATA, Up to 10TB per HDD |
| Network Interface | 2×RJ45 10/100/1000M self-adaptive |
| USB | Front: 1×USB2.0, Rear: 1×USB2.0 + 1×USB3.0 |
| Power Supply | DC 12V/3A |
| Power Consumption | ≤12W (without HDD) |
| Working Temp & Humidity | -10°C ~ +55°C, ≤90% RH |
| Dimensions & Weight | 380×315×53 mm, ≤2kg (without HDD) |
| Certification | |
| Certification | CE, FCC, UL, RoHS, WEEE |
