| Camera Specifications | |
|---|---|
| Camera | |
| Image Sensor | 1/2.9″ Progressive Scan CMOS |
| Max. Resolution | 2688 × 1520 |
| Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON) 0 Lux with light |
| Shutter Time | 1/3 s to 1/100,000 s |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0°–360°; Tilt: 0°–90°; Rotate: 0°–360° |
| Lens | |
| Lens Type | Fixed focal lens, 2.8, 4, and 6 mm optional |
| Focal Length & FOV | 2.8 mm: H 104°, V 57°, D 122° 4 mm: H 84°, V 45°, D 100° 6 mm: H 52°, V 28°, D 61° |
| Lens Mount | M12 |
| Iris Type | Fixed |
| Aperture | F1.6 |
| Depth of Field | 2.8 mm: 1.4 m to ∞ 4 mm: 1.5 m to ∞ 6 mm: 3.5 m to ∞ |
| DORI Distance | |
| 2.8 mm | Detect: 63 m; Observe: 25 m; Recognize: 12 m; Identify: 6 m |
| 4 mm | Detect: 78 m; Observe: 31 m; Recognize: 15 m; Identify: 7 m |
| 6 mm | Detect: 128 m; Observe: 50 m; Recognize: 25 m; Identify: 12 m |
| Illuminator | |
| Supplement Light Type | IR, White Light |
| Supplement Light Range | -2LI/-2LI2U: up to 60 m -4LI/-4LI2U: up to 80 m |
| Smart Supplement Light | Yes |
| IR Wavelength | 850 nm |
| Video | |
| Main Stream | 50 Hz: 25 fps (2688×1520, 1920×1080, 1280×720) 60 Hz: 30 fps (2688×1520, 1920×1080, 1280×720) |
| Sub-Stream | 50 Hz: 25 fps (1280×720, 640×480, 640×360) 60 Hz: 30 fps (1280×720, 640×480, 640×360) |
| Third Stream | 50 Hz: 10 fps (1920×1080, 1280×720, 640×480, 640×360) 60 Hz: 10 fps (1920×1080, 1280×720, 640×480, 640×360) *Supported under certain settings |
| Video Compression | Main: H.265/H.264/H.264+/H.265+ Sub: H.265/H.264/MJPEG Third: H.265/H.264 |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline, Main, High Profile |
| H.265 Type | Main Profile |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Bit Rate Control | CBR, VBR |
| Region of Interest (ROI) | 1 fixed region for main and sub-stream |
| Target Cropping | Yes |
| Audio | |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC (-2LI2U/-4LI2U) |
| Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32–160 Kbps (MP2L2)/8–320 Kbps (MP3)/16–64 Kbps (AAC-LC) |
| Audio Sampling Rate | 8/16/32/48 kHz |
| Environment Noise Filtering | Yes |
| Network | |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets |
| Simultaneous Live View | Up to 6 channels |
| API | ONVIF (Profile S, G), ISAPI, SDK, ISUP |
| Security | Password protection, HTTPS encryption, IP filter, Security Audit Log, TLS 1.1/1.2/1.3, WSSE |
| User/Host | Up to 32 users, 3 levels: administrator, operator, user |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Network Storage | NAS (NFS, SMB/CIFS), ANR, memory card support/encryption |
| Web Browser | IE 11 (plugin), Chrome/Firefox/Edge/Safari (plugin-free), local service supported |
| Image | |
| Image Parameters Switch | Yes |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Image Settings | Rotate mode |
| Wide Dynamic Range (WDR) | 120 dB |
| SNR | ≥ 52 dB |
| Image Enhancement | BLC, HLC, 3D DNR |
| Privacy Mask | 8 programmable polygon masks |
| Interface | |
| Ethernet Interface | 1 RJ45 10/100 M self-adaptive |
| On-Board Storage | microSD/microSDHC/microSDXC up to 512 GB |
| Reset Key | Yes |
| Event | |
| Basic Event | Motion detection, video tampering, exception |
| Smart Event | Face detection |
| Linkage | Upload to FTP/NAS/memory card, notify center, send email, trigger recording/capture |
| Deep Learning Function | Perimeter protection: Line crossing, intrusion, alarm by human/vehicle |
| General | |
| Power | -2LI/-2LI2U: 12 VDC ±25%, 0.58 A, max 7 W, PoE: 8.5 W -4LI/-4LI2U: 12 VDC ±25%, 0.83 A, max 10 W, PoE: 11 W |
| Material | Metal |
| Dimension | 88.7 × 93.1 × 286.7 mm (3.5″ × 3.7″ × 11.3″) |
| Package Dimension | 386 × 156 × 155 mm (15.2″ × 6.1″ × 6.1″) |
| Weight | Approx. 1150 g (2.5 lb) |
| With Package Weight | Approx. 1640 g (3.6 lb) |
| Storage Conditions | -30 °C to 60 °C, Humidity ≤95% (non-condensing) |
| Startup and Operating Conditions | -30 °C to 60 °C, Humidity ≤95% (non-condensing) |
| Language | 33 languages including English, Russian, French, Chinese, Japanese, Korean, etc. |
| General Function | Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding |
| Approval | |
| EMC | CE-EMC: EN 55032:2015+A1:2020, EN 50130-4, EN IEC 61000-3-2, EN 61000-3-3, RCM, IC, KC |
| Safety | CB: IEC 62368-1, CE-LVD: EN 62368-1, BIS: IS 13252, LOA: IEC/EN 60950-1 |
| Environment | CE-RoHS, WEEE, Reach |
| Protection | IP67: IEC 60529-2013 |
| Protection Level Description | |
| Top-level protection | For professional anti-corrosion environments (coastlines, docks, chemical plants) |
| Moderate protection | Moderate anti-corrosion areas, e.g., ~2 km from coastlines, acid rain-affected zones |
| No specific protection | Areas without special anti-corrosion requirements |
