| Camera | |
|---|---|
| Image Sensor | 1/2.4″ Progressive Scan CMOS |
| Max. Resolution | 3200 × 1800 |
| Shutter Time | 1/3 s to 1/100,000 s |
| Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Lens | |
| Lens Type | Fixed focal lens, 2.8 and 4 mm optional |
| Focal Length & FOV | 2.8 mm: H FOV 105°, V FOV 55°, D FOV 127° 4 mm: H FOV 78°, V FOV 38°, D FOV 96° |
| Lens Mount | M12 |
| Iris Type | Fixed |
| Aperture | F1.6 |
| DORI | |
| 2.8 mm | D: 76 m, O: 30 m, R: 15 m, I: 7 m |
| 4 mm | D: 115 m, O: 45 m, R: 23 m, I: 11 m |
| Illuminator | |
| Supplement Light Type | IR, White Light |
| Supplement Light Range | Up to 30 m |
| Smart Supplement Light | Yes |
| IR Wavelength | 850 nm |
| Video | |
| Main Stream | 50 Hz: 20 fps (3200×1800, 2688×1520, 1920×1080, 1280×720) 60 Hz: 20 fps (same resolutions) |
| Sub-Stream | 50 Hz: 20 fps (1280×720, 640×480, 640×360) 60 Hz: 20 fps (same resolutions) |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline/Main/High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR, VBR |
| Region of Interest (ROI) | 1 fixed region for main stream |
| Audio | |
| Audio Type | Mono sound |
| Environment Noise Filtering | Yes |
| Audio Sampling Rate | 8 kHz/16 kHz |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1/G.726)/32–160 Kbps (MP2L2)/16–64 Kbps (AAC-LC) |
| Network | |
| Security | Password protection, complicated password, watermark, basic and digest authentication, audit log, host authentication (MAC) |
| Simultaneous Live View | Up to 6 channels |
| API | ONVIF (Profile S/T/G), ISAPI, SDK |
| Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP |
| User/Host | Up to 32 users (admin/operator/user) |
| Client | iVMS-4200, Hik-Connect |
| Web Browser | IE10/11 (plug-in), Chrome 57+, Firefox 52+, Edge 89+ |
| Image | |
| Wide Dynamic Range (WDR) | 120 dB |
| SNR | ≥ 52 dB |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR |
| Image Settings | Rotate, saturation, brightness, contrast, sharpness, gain, white balance |
| Privacy Mask | 4 programmable polygon masks |
| Interface | |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive |
| On-Board Storage | MicroSD/microSDHC/microSDXC up to 256 GB (-F) |
| Built-in Microphone | Yes |
| Reset Key | -F: Yes |
| Event | |
| Basic Event | Motion detection, tampering alarm, exception |
| Linkage | FTP upload, email, notify surveillance center, trigger recording/capture (-F) |
| General | |
| Power | 12 VDC ±25%, 0.41 A max 5 W, Ø5.5 mm coaxial plug, PoE IEEE 802.3af max 6.5 W |
| Material | Metal & Plastic |
| Dimension | 170.8 × 66 × 69.1 mm (6.7″ × 2.6″ × 2.7″) |
| Package Dimension | 216 × 121 × 118 mm (8.5″ × 4.8″ × 4.6″) |
| Weight | Approx. 285 g (0.6 lb.) |
| With Package Weight | Approx. 481 g (1.1 lb.) |
| Storage Conditions | -30 °C to 60 °C, humidity ≤95% (non-condensing) |
| Startup/Operating Conditions | -30 °C to 60 °C, humidity ≤95% (non-condensing) |
| Language | English, Ukrainian |
| General Function | Heartbeat, anti-banding, mirror, password protection, reset via email |
| Approval | |
| EMC | CE-EMC: EN 55032:2015, EN 61000-3-2:2019, EN 50130-4:2011+A1:2014, RCM: AS/NZS CISPR 32:2015, IC: ICES-003 Issue 7 |
| Safety | UL 62368-1, CB IEC 62368-1:2014+A11, CE-LVD EN 62368-1:2014/A11:2017, BIS IS 13252 |
| Environment | CE-RoHS, WEEE, Reach |
| Protection | IP67: IEC 60529-2013 |
