| Camera Specification |
|---|
| Camera |
|---|
| Sensor | 1/3″, 5.0 megapixel, progressive scan, CMOS |
| Minimum Illumination | Color: 0.01 lux (F2.1, AGC ON), 0 lux with IR on |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Shutter | Auto/Manual, 1 ~ 1/100000s |
| Pan/Tilt | Pan: 3° ~ 360°, Tilt: 0° ~ 68° |
| S/N Ratio | >52 dB |
| WDR | DWDR |
| Lens |
|---|
| Lens Type | IPC325LB-SF28-A: 2.8mm@F2.1, IPC325LB-SF40-A: 4.0mm@F2.1 |
| Iris | Fixed |
| Field of View (H) | 2.8mm: 97°, 4.0mm: 79° |
| Field of View (V) | 2.8mm: 52.2°, 4.0mm: 42.3° |
| Field of View (D) | 2.8mm: 107.5°, 4.0mm: 85.1° |
| DORI |
|---|
| DORI Distance (Lens) | 2.8mm, 4.0mm |
| Detect | 2.8mm: 63m, 4.0mm: 90m |
| Observe | 2.8mm: 25.2m, 4.0mm: 36m |
| Recognize | 2.8mm: 12.6m, 4.0mm: 18m |
| Identify | 2.8mm: 6.3m, 4.0mm: 9m |
| Illuminator |
|---|
| IR Range | Up to 30m |
| Wavelength | 850nm |
| IR Control | Auto/Manual |
| Video |
|---|
| Compression | Ultra265, H.265, H.264, MJPEG |
| H.264 Profile | Baseline, Main, High |
| Main Stream Frame Rate | 5MP: 20fps, 4MP: 20fps, 3MP: 20fps, 2MP: 30fps |
| Sub Stream Frame Rate | D1, 640×360, 2CIF, CIF up to 30fps |
| Bit Rate | 128 Kbps ~ 6144 Kbps |
| Features | Dual streams, OSD up to 4, Privacy Mask up to 4, ROI up to 8 |
| Image |
|---|
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Noise Reduction | 2D/3D DNR |
| Smart IR | Support |
| Flip | Normal/Vertical/Horizontal/180° |
| Dewarping | N/A |
| HLC | Support |
| BLC | Support |
| Defog | Digital Defog |
| Events & General Functions |
|---|
| Detection | Motion detection |
| General Functions | Watermark, IP Filtering, Access Policy, ARP Protection, RTSP & HTTP Authentication, User Authentication |
| Network & Security |
|---|
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, UPnP, HTTP, HTTPS, SMTP, QoS, SSL/TLS |
| Integration | ONVIF (Profile S, T), API, SDK |
| User | Up to 32 users, 2 levels (Administrator & Common) |
| Security | Password protection, HTTPS encryption, Export logs, Digest & WSSE authentication |
| Interface |
|---|
| Audio/Alarm/Serial | N/A |
| Built-in Mic/Speaker/WiFi | N/A |
| Network | 1 × RJ45 10M/100M Base-TX Ethernet |
| Video Output | N/A |
| Certification & Protection |
|---|
| EMC | CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035), FCC (FCC 47 CFR part15 B) |
| Safety | CE LVD, CB, UL/CUL |
| Environment | CE-RoHS, WEEE |
| Protection | IP67, IK10 |
| General |
|---|
| Power | DC 12V ±25%, PoE (IEEE 802.3af), Max 5W |
| Power Interface | Ø5.5mm coaxial |
| Dimensions | Ø109 × 81 mm (4.3” × 3.2”) |
| Weight | 0.32kg (0.71lb) |
| Material | Metal + Plastic |
| Operating Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity ≤95% RH |
| Storage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity ≤95% RH |
| Surge Protection | 4KV |
| Reset Button | N/A |
| Web Client Language | English |
