Technical Specification
Model
Models	NVR304-16B-IQ, NVR304-32B-IQ
Decoding
Decoding Format	Ultra265, H.265, H.264
Decoding Capability	NVR304-16B-IQ: Smart Off: 2×12MP@30, 2×4K@30, 4×4MP@30, 10×1080P@30, 16×720P@30 Smart On: 2×4K@30, 4×4MP@30, 8×1080P@30, 16×720P@30 NVR304-32B-IQ: Smart Off: 2×12MP@30, 2×4K@30, 4×4MP@30, 10×1080P@30, 20×720P@30, 32×D1 Smart On: 2×4K@30, 4×4MP@30, 8×1080P@30, 16×720P@30, 32×D1
Audio Compression	G.711A, G.711U
Network
Incoming Bandwidth	160 Mbps
Outgoing Bandwidth	128 Mbps
Remote Users	128
Protocols	TCP/IP, P2P, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, RTSP, IPv6, IPv4, 802.1x
Browser (Plugin)	Windows: IE10/11, Firefox ≥52, Chrome ≥45, Edge ≥79
Video/Audio Input
IP Video Input	NVR304-16B-IQ: 16-ch, NVR304-32B-IQ: 32-ch
RCA Audio Input	1-ch
Video/Audio Output
HDMI Output	4K@30Hz, 1080p@60/50Hz, 1600×1200@60Hz, 1280×1024@60Hz, 1280×720@60Hz, 1024×768@60Hz
VGA Output	1080p@60/50Hz, 1600×1200@60Hz, 1280×1024@60Hz, 1280×720@60Hz, 1024×768@60Hz
RCA Audio Output	1-ch
Liveview Display	NVR304-16B-IQ: 1/4/6/8/9/16 NVR304-32B-IQ: 1/4/6/8/9/16/25/32
Corridor Mode Screen	NVR304-16B-IQ: 3/4/5/7/9/10/12/16 NVR304-32B-IQ: 3/4/5/7/9/10/12/16/32
Two-way Audio
Two-way Audio	1-ch, RCA (using audio input/output)
Snapshot
Snapshot	FTP/Schedule/Event, 4-ch snapshot, up to D1 resolution
Recording
Recording Resolution	12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/D1/2CIF/CIF
Synchronous Playback	16-ch
Smart Features
VCA Detection	Face Detection, Vehicle Detection, SIP (Intrusion, Cross Line, Enter/Leave Area), UMD, People Counting, Traffic Monitoring
Smart by NVR	Face Detection, Smart Intrusion Prevention, UMD
VCA Search	Motor/Non-Motor Vehicle, Human Body, General Search, People Counting Report, Heat Map
Vehicle Picture Library	Up to 5 libraries, 25,000 vehicle pictures in total
SIP by NVR	2-ch
UMD by NVR	4-ch
Alarm
General Alarm	Defocus Detection, Scene Change, Object Left/Removed, Auto Tracking, Motion, Tampering, Human Body, Video Loss, Alarm Input, Audio Detection
Alert Alarm	IP Conflict, Network Disconnected, Disk Offline/Abnormal, Illegal Access, Disk Space Low/Full, Recording/Snapshot Abnormal
GUI Language
GUI Language	38 languages including Chinese, English, Vietnamese, Thai, Turkish, Spanish, Portuguese, French, German, Italian, Dutch, Polish, Russian, Hebrew, Arabic, Korean, Japanese, Persian…
Hard Disk
SATA Interfaces	4
Capacity	Up to 10TB per HDD
External Interface
Network Interface	2×RJ45 10/100/1000M
USB Interface	Front: 1×USB2.0, Rear: 1×USB2.0 + 1×USB3.0
RS485/RS232/Alarm In/Alarm Out	N/A
Power & Environment
Power Supply	DC 12V/5A
Working Temperature	-10°C ~ +55°C
Working Humidity	≤90% RH (non-condensing)
Power Consumption (without HDD)	≤12W
Physical
Dimensions (W×D×H)	440×350×48 mm (17.3″×13.8″×1.9″)
Weight (without HDD)	≤3.4 kg (7.5 lb)
Certification
Certification	CE, FCC, UL, RoHS, WEEE
CE Standards	EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035
FCC Standards	Part15 Subpart B
