توضیحات
| Camera | |
|---|---|
| Image Sensor | 1/1.8″ Progressive Scan CMOS |
| Max. Resolution | 3200 × 1800 |
| Min. Illumination | Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light |
| Shutter Time | 1/3 s to 1/100,000 s |
| Day & Night | IR cut filter |
| Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Lens | |
| Lens Type | Fixed focal lens, 2.8 and 4 mm optional |
| Focal Length & FOV | 2.8 mm: HFOV 105.1°, VFOV 54.8°, DFOV 128.2° 4 mm: HFOV 90.0°, VFOV 45.8°, DFOV 109.4° |
| Lens Mount | M16 |
| Iris Type | Fixed |
| Aperture | F1.0 |
| Depth of Field | 2.8 mm: 3.3 m to ∞ 4 mm: 3.8 m to ∞ |
| DORI | |
| DORI | 2.8 mm: D: 89 m, O: 35 m, R: 17 m, I: 8 m 4 mm: D: 109 m, O: 43 m, R: 21 m, I: 10 m |
| Illuminator | |
| Supplement Light Type | IR, White Light |
| Supplement Light Range | Up to 60 m |
| Smart Supplement Light | Yes |
| IR Wavelength | 850 nm |
| Video | |
| Main Stream | 50 Hz: 25 fps (3200×1800, 2688×1520, 1920×1080, 1280×720) 60 Hz: 24 fps (3200×1800), 30 fps (2688×1520, 1920×1080, 1280×720) |
| Sub-Stream | 50 Hz: 25 fps (1280×720, 640×480, 640×360) 60 Hz: 30 fps (1280×720, 640×480, 640×360) |
| Third Stream | 50/60 Hz: 10 fps (1920×1080, 1280×720, 640×480, 640×360) |
| Video Compression | Main: H.265/H.264/H.264+/H.265+ Sub: H.265/H.264/MJPEG Third: H.265/H.264 |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile, Main Profile, High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR, VBR |
| ROI | 1 fixed region for main stream and sub-stream |
| Audio | |
| Audio Type | Mono sound |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Bit Rate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32–192 Kbps (MP2L2)/8–320 Kbps (MP3)/16–64 Kbps (AAC-LC) |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering | Yes |
| Network | |
| Protocols | TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, SNMP, IPv4/IPv6, QoS, UPnP, SSL/TLS, PPPoE, etc. |
| Simultaneous Live View | Up to 6 channels |
| API | ONVIF (Profile S/G/T), ISAPI, SDK, ISUP |
| User/Host | Up to 32 users; 3 levels: admin, operator, user |
| Security | Password protection, HTTPS, 802.1X, watermark, TLS 1.3, IP filter, audit log, etc. |
| Network Storage | NAS (NFS, SMB/CIFS), ANR |
| Client | iVMS-4200, Hik-Connect, Hik-Central |
| Web Browser | Plug-in: IE10/11 Plug-in free: Chrome 57+, Firefox 52+, Edge 89+ |
| Image | |
| Image Parameters Switch | Yes |
| Image Settings | Rotate, saturation, brightness, contrast, sharpness, gain, white balance (via client/web) |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR, Defog |
| SNR | ≥ 52 dB |
| WDR | 130 dB |
| Privacy Mask | 4 programmable polygon masks |
| Interface | |
| Ethernet Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
| On-Board Storage | microSD/microSDHC/microSDXC, up to 512 GB |
| Built-in Microphone | Yes |
| Built-in Speaker | 2 W, 97 dB @10cm |
| Audio I/O | 1 in / 1 out (max 3.3 Vpp, non-equilibrium) |
| Alarm | 1 input, 1 output (max 24 VDC/24 VAC, 1 A) |
| Reset Key | Yes |
| Event | |
| Basic Event | Motion detection, video tampering, exception |
| Smart Event | Scene change detection |
| Linkage | Upload to FTP/NAS/memory, email, alarm output, recording, capture, audible warning, strobe |
| Face Capture | Yes |
| Perimeter Protection | Line crossing, intrusion, region entrance/exit (human & vehicle) |
| General | |
| Power | 12 VDC ±25%, PoE IEEE 802.3af, Max 12.5 W |
| Material | Metal (front, body, bracket) |
| Dimension | 286.7 × 93.3 × 91.2 mm (11.3″ × 3.7″ × 3.6″) |
| Weight | Approx. 1205 g (2.7 lb) |
| With Package Weight | Approx. 1920 g (4.2 lb) |
| Operating Conditions | -30 °C to 60 °C, ≤95% RH (non-condensing) |
| Storage Conditions | -30 °C to 60 °C, ≤95% RH (non-condensing) |
| Functions | Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding |
| Language | 33 languages (EN, RU, DE, FR, ES, IT, CN, JP, etc.) |
| Approval | |
| EMC | CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021 |
| Safety | UL 62368-1, CB IEC 62368-1:2014+A11, CE-LVD EN 62368-1:2014/A11:2017 |
| Environment | CE-RoHS: 2011/65/EU |
| Protection | IP67: IEC 60529-2013 |
