| Camera | |
|---|---|
| Resolution | 5MP |
| Sensor | 1/3.0″ CMOS |
| Min. Illumination | Color: 0.01 lux (F2.1, AGC ON), 0 lux with IR on |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Shutter | Auto/Manual, 1 ~ 1/100000s |
| Adjustment Angle | Pan: 0° ~ 360°, Tilt: 0° ~ 90°, Rotate: 0° ~ 360° |
| S/N Ratio | >52dB |
| WDR | DWDR |
| Lens | |
| Lens Type | IPC2125LB-SF28-A: 2.8mm, IPC2125LB-SF40-A: 4.0mm |
| Iris Type | Fixed, F2.1 |
| Field of View (H) | 97° (2.8mm), 79° (4.0mm) |
| Field of View (V) | 52.2° (2.8mm), 42.3° (4.0mm) |
| Field of View (D) | 107.5° (2.8mm), 85.1° (4.0mm) |
| DORI | |
| Detect | 63m (2.8mm), 90m (4.0mm) |
| Observe | 25.2m (2.8mm), 36m (4.0mm) |
| Recognize | 12.6m (2.8mm), 18m (4.0mm) |
| Identify | 6.3m (2.8mm), 9m (4.0mm) |
| Illuminator | |
| IR Range | Up to 30m |
| Wavelength | 850nm |
| IR Control | Auto/Manual |
| Video | |
| Compression | Ultra 265, H.265, H.264, MJPEG |
| H.264 Profile | Baseline, Main, High |
| Main Stream | 5MP 20fps, 4MP 20fps, 3MP 20fps, 2MP 1080P 30fps |
| Sub Stream | D1, 640×360, 2CIF, CIF up to 30fps |
| Bit Rate | 128 Kbps ~ 6144 Kbps |
| OSD / Privacy / ROI | Up to 4 OSDs, 4 Privacy Masks, 8 ROI areas |
| Image | |
| White Balance | Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2 |
| Digital Noise Reduction | 2D / 3D DNR |
| Smart IR | Support |
| Flip | Normal / Vertical / Horizontal / 180° |
| HLC / BLC | Support |
| Defog | Digital Defog |
| Events & Functions | |
| Basic Detection | Motion Detection |
| General Functions | Watermark, IP Filtering, Access Policy, ARP Protection, RTSP & HTTP Authentication, User Authentication |
| Network | |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, UPnP, HTTP, HTTPS, 802.1x, QoS, SSL/TLS, SMTP |
| Integration | ONVIF (Profile S, T), API, SDK |
| User / Host | Up to 32 users, 2 levels: admin / common |
| Security | Password protection, HTTPS, RTSP/HTTP authentication, WSSE for ONVIF |
| Client / Browser | EZStation, EZView, EZLive; IE10+, Chrome 45+, Firefox 52+, Edge 79+ |
| Interface | |
| Audio / Alarm / Serial / Mic / Speaker / WiFi | N/A |
| Network | 1 × RJ45 10M/100M Base-TX Ethernet |
| Video Output | N/A |
| Certification & Safety | |
| EMC | CE-EMC, FCC |
| Safety | CE LVD, CB, UL/CUL |
| Protection | IP67, 4KV surge protection |
| Power & Environment | |
| Power | DC 12V±25%, PoE (IEEE 802.3af), Max 5W |
| Dimensions | 161 × 63 × 62 mm |
| Weight | 0.36 kg |
| Material | Graphene + Plastic |
| Working Environment | -30°C ~ 60°C, Humidity ≤95% RH (non-condensing) |
| Storage Environment | -30°C ~ 60°C, Humidity ≤95% RH (non-condensing) |
